Description
Safety Features:
1. Precision machined safety lock
2. Safety descending stop & alarm
3. Safety valve for anti-explosion of the hydraulic system
4. Height limit switch
5. EVA Rubber mat (4pcs/set)
3.5 T Capacity APO-E35 Full Rise Scissor Lift
The APO-E35 full rise scissor lift is a low profile 3500kg capacity double scissor lift was engineered with efficiency and productivity in mind. The APO-E35 full rise scissor lift can easily lift all makes and models (within rated capacity) with a synchronized hydraulic system. The APO-E35 full rise scissor lift also offers free access all around the lifted vehicle and between platforms, with a crossmember free design providing an uncluttered and hazard-free work area. The APO-E35 full rise scissor lift is availble flush mount, and surface mount.
Additional information
| Model | APO-E35 |
|---|---|
| Lifting Capacity | 3500 KG(7,716 lbs) |
| Lifting Height | 2050 mm(80") |
| Platform Height | 330 mm(13") |
| Platform Length | 1450-1750 mm(57"-68.9") |
| Power Supply | 220V 1PH 50/60Hz 2.2KW, 220/380V 3PH 50/60Hz 2.2KW |
| Release | Pneumatic Lock Release |
